CTK Doorkit Standard damping package
Shipping costs starting from
4,90€
″CTK Doorkit is a ready-made damper kit to damper two doors very effectively... The kit contains three different damper materials and installation instructions.
The Standard Pro mat reduces the vibration of the door leaf and makes the door leaf very sturdy.
The Elastic mat is designed to be glued on top of the Standard Pro mat for even more effective damping.
Linefix is a porous material that reduces noise and is designed to be glued behind the door curtain.
The mats bend well and do not require separate heating of the mat for installation.
Contents of the package:
Standard Pro carpet.
Dimensions: 370 x 500 x 2mm
Quantity: 8 pieces (total 1,48m²)
Elastic
Dimensions: 370 x 500 x 6mm
Quantity: 2 pieces (total 0,37m²)
Linefix
Dimensions: 370 x 500 x 7mm
Quantity: 4pcs (0,74m²)
″self-adhesive mat damping vibrations and vibrations of a professional class
total thickness: 2.0 mm +/- 0.2 mm
aluminium foil thickness: 0.1 mm (100 µm)
material: high-tech composite of butyl rubber and specialized polymers of very high viscosity, reinforced with aluminium foil
MLF (mechanical loss factor) - vibration damping efficiency: 0.30
sheet dimensions: 370x500 mm (0.185 m2)
weight of 1 sheet: 0.65 kg (3.51 kg / m2)
recommended installation temperature: + 10ºC to + 30ºC
temperature range of use and operation: -50ºC to + 140ºC
high flexibility and high efficiency in a wide temperature range.
The Standard Pro mat reduces the vibration of the door leaf and makes the door leaf very sturdy.
The Elastic mat is designed to be glued on top of the Standard Pro mat for even more effective damping.
Linefix is a porous material that reduces noise and is designed to be glued behind the door curtain.
The mats bend well and do not require separate heating of the mat for installation.
Contents of the package:
Standard Pro carpet.
Dimensions: 370 x 500 x 2mm
Quantity: 8 pieces (total 1,48m²)
Elastic
Dimensions: 370 x 500 x 6mm
Quantity: 2 pieces (total 0,37m²)
Linefix
Dimensions: 370 x 500 x 7mm
Quantity: 4pcs (0,74m²)
″self-adhesive mat damping vibrations and vibrations of a professional class
total thickness: 2.0 mm +/- 0.2 mm
aluminium foil thickness: 0.1 mm (100 µm)
material: high-tech composite of butyl rubber and specialized polymers of very high viscosity, reinforced with aluminium foil
MLF (mechanical loss factor) - vibration damping efficiency: 0.30
sheet dimensions: 370x500 mm (0.185 m2)
weight of 1 sheet: 0.65 kg (3.51 kg / m2)
recommended installation temperature: + 10ºC to + 30ºC
temperature range of use and operation: -50ºC to + 140ºC
high flexibility and high efficiency in a wide temperature range.
- EAN: 6430042128723
- SKU: 103411626
- Vendor material number: CTK DOORKIT STANDARD
