Schneider Exxact Uni400Led white light controller
UNI400LED is a light controller with a wide power range, with a minimum power of 4 W.
Shipping costs starting from
3,90€
UNI400LED is a light controller with a wide power range, with a minimum power of 4 W. In addition to traditional lamp loads, it is approved for the control of dimmable LED lamps and lamps. UNI400LED is a recommended choice even when the light controller is connected to a lamp socket, and the light source is not known during the installation phase. UNI400LED does not need a neutral wire, so it can be installed in place of an existing switch. It is also suitable for stair light switching. The maximum and minimum level of the light control range can be adjusted. Short-circuit and overload protection is electronic (no fuse).
- Color white
- Load type: general purpose and renovation
- LEDRAL number (equivalent): 9003
- Assembly: basic element with center plate
- Nominal voltage range: 230 V
- App control (Bluetooth): no
- Connection method: screw connection
- Minimum depth (built-in device case): 40 mm
- Device width: 71 mm
- Device height: 71 mm
- Device depth: 29 mm
- Dimming rising edge control: yes
- Dimming falling edge control: yes
- Conductor cross-section: 1.5-2.5 mm²
- Fastening method: screw fastening
- Installation method: flush mounting
- Mode of operation: twist/button
- Frequency: 50 Hz
- Crown light control: no
- Material quality: other
- Material: other
- Halogen-free: yes
- Lighting level memory: no
- Suitable for enclosure class (IP): IP20
- Can be used with button: no
- Can be used with a motion sensor: no
- Can be used with presence detector: no
- Can be used with clock switch/timer: no
- Can be used with RF button: no
- Usable with IR button: no
- Transparent: no
- Surface material: glossy
- Surface protection: untreated
- Substation input: yes
- Impact resistance class: IK02
- Warranty: 2 vuosi
- EAN: 3606480686092
- SKU: 103210825
- Vendor material number: 2622225
