Take sound reproduction to a new level with SounDigital EVO5 series amplifiers – compact size, lots of power and speaker-level input in the same package!
Never before have such small external dimensions been able to produce such great power. And at a very reasonable price!
All models have a damping factor of over 1000!
At high power, a lot of power is consumed, and in many cars the problem is that the voltage drops at the peak of the music and when playing loudly.
Sounddigital's amplifiers have taken this practical situation into account so that the operating voltage of the amplifiers can be as low as 9 volts!
SounDigital operates in a very rare way as an amplifier manufacturer these days, ALL models are designed and manufactured in our own production facility in Brazil. Power @ 2Ω: 800W Power @ 4Ω: 528W Power @ 8Ω: 348W
Frequency Response:
10Hz ~ 20kHz
Subsonic Filter (HP 12dB/8º):
10Hz~80Hz
Low Pass Filter (LP 12dB/8º):
50Hz ~ 20kHz
Operating Voltage:
8V ~ 16V
SNR:
2Ω: 96dB 4Ω: 97dB
Input Sensitivity (RCA): 0.2V ~ 4V
Input Sensitivity (High Level input): 1.5V ~ 15V
Current Draw (Music): 2Ω: 40A
Current Draw With Resistive Load (1kHz @ 12.6V): 2Ω: 81A
Total Efficiency: 2Ω: 79%
Damping Factor (@100Hz Rated Impedance): 200
Power Cable: 10mm² (7AWG)
Audio Output Cable: 2 x 2mm² (12 AWG)
Recommended Fuse (Music): 40A
Recommended Battery (Music): 60Ah
Width: 4.4 in / 11.3 cm
Length: 5.8 in / 14.8 cm
Height: 2 in / 5.1 cm
Weight: 1.54 lb / 0.7 Kg
EAN:
7898644527150
SKU:
103375977
Vendor material number:
SD800.1-2 EVO5
Only available in the online store, not available in classic stores
